Corrosion Resistance

L46104AT

Specification
Load Capacity: 45 kg
Extension: Full Extension
Installation Space: 12.7 mm
Length Range: 300 mm – 550 mm
Slide Height: 45.7 mm
Material: Stainless Steel
Features:
‧ Non-handed: Universal design for left or right side installation
‧ Detent-in: Keeps the drawer securely closed
‧ Lever Disconnect: Released by trigger for easy drawer removal
‧ Adjustable Side Space Tabs: Simplifies installation adjustments
Hole Pattern: Standard 32 mm system hole pitch

Description

  • Tactical vehicle storage and mobile equipment
  • Medical and laboratory cabinetry
  • Food service and outdoor storage solutions
Added to Inquiry list.
Finish
SS(Stainless Steel)
Customization available.
